MAXIMUM BUILD SIZE

RAPMAN 3.2 SINGLE HEAD

RAPMAN 3.2 DOUBLE HEAD(single head print)

X Axis

270mm (10 ⅝ inches)

190mm (7 ½ inches)

Y Axis

205mm (8 inches)

205mm (8 inches)

Z Axis

210mm (8 ¼ inches)

210mm (8 ¼ inches)

Please note print size will vary from build size and is dependent on print material specifications

We recommend that you limit ABS prints to 100mm (x) by100mm (y) and PLA prints to 200mm (x) by 200mm (y). Larger prints may be accomplished within the constraints of the machine depending on geometry.

Z Axis Resolution

0.125mm (0.005 inches / 125 microns)

0.125mm (0.005 inches / 125 microns)

Print Tolerance

  x and y axis +/- 1% of object dimension or +/-0.2mm (0.008”/200 microns) whichever is greater

  z axis +/- half the processed z resolution

  Shrinkage and warping can occur on models and is material and geometry dependent.

Print Speed Extruded Volume

Maximum 15mm³ (⁹⁄₁₆^th”³) per second print and polymer dependent.

Power Requirements

60 Watts (5A @ 12V)

Approx. Weight

17kg (37.5 Lbs)

Overall Dimensions Exc. - Extruder

490mm (w) x 500mm (l) x 510mm (h)

Overall Dimensions Inc. - Extruder

490mm (w) x 500mm (l) x 820mm (h)

Maximum Extruder Operating Temperature

280^oC (536^oF)

MAXIMUM BUILD SIZE

3DTouch™ Single head print

3DTouch™
Double head print

3DTouch™
Triple head print

X axis

275mm (10.75 inches)

230mm (9 inches)

185mm (7.3 inches)

y axis

275mm (10.75 inches)

275mm (10.75 inches)

275mm (10.75 inches)

z axis

201mm (7.9 inches)

201mm (7.9 inches)

201mm (7.9 inches)

Please note print size will vary from build size and is dependent on print material specifications

We recommend that you limit ABS prints to 100mm (x) by100mm (y) and PLA prints to 200mm (x) by 200mm (y). Larger prints may be accomplished within the constraints of the machine depending on geometry.

Z axis resolution

0.125mm (0.005” / 125 microns)

0.125mm (0.005” / 125 microns)

0.125mm (0.005” / 125 microns)

Print tolerance

   x and y axis +/- 1% of object dimension or +/- 0.2mm (0.008” / 200 microns) whichever is greater

   z axis +/- half the processed z resolution

   Shrinkage and warpage can occur on models and is purely geometry dependent.

Print speed extruded volume

Maximum 15mm³ (⁹⁄₁₆^th”³ ) per second print and polymer dependent

Power requirements

110 - 240v AC

Approximate weight

36kg (79 Lbs.)

37kg (81.5 Lbs.)

38kg (84 Lbs.)

Overall dimensions

515mm (w) x 515mm (l) x 598mm (h) (20 ¼” x 20 ¼” x 23 ½” inches)

Maximum operating temperature at extruder tip

280^oC (536^oF)

Support material

PLA / ABS / Soluble Clear translucent PLA

Support removal

Break away support material with pliers and cutters or just fingers where appropriate.  Clear translucent PLA is soluble in a sodium hydroxide solution used with a heated ultrasonic tank - care is required with this option.
